Model 55/56 User Guide Issue 4, June 2002

Studio Technologies, Inc. Page 11

Model 38, boosted by its preamp, and

then combined with the stereo cue mix

supplied by the Model 55. This provides

each Model 38 with an individual head-

phone mix, solving the classic problem of

Connects to additional

talent amplifiers

Connects to the Model 55 or another talent

amplifier’s loop thru connector

Model 35 Back Panel

Model 35 Front Panel

Two headphone

outputs

Power present

LED

Headphone output

level control

Switch between

stereo and mono

(L+R) output

wanting “more me” in the phones! Like the

Model 35, the Model 38 is linked with a

Model 55 Central Controller by a single

cable.
